ED8416TCPR | 5MP 16CH 5-IN1 Hybrid DVR | Up To 20 IPC
SKU: WECED8416TCPR- 16 CH TVI / AHD 2.0 video input, 16 CH 1080P / 1080P lite / 720P 16 CH TVI / CVI / AHD video input
- 16 CH 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 recording
- 4 CH IPC 4MP / 3MP / 1080P / 960P / 720P recording (Up To 20 IPC)
- Adopt standard H.264 high profile compression format to get high-quality video at much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timer / motion / sensor
- Playback : 16 CH simultaneously playback
- Search: time slice, time, event ( manual, sensor, motion ), tag search
- Express and flexible backup via USB, network and so on
- Pentaplex: preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
- Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously
- Authorization management, log review and device status review
- HDMI 1080P output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QRCode scanning by mobile phone and PAD
- Powerful smart phone & Pad surveillance with iOS and Andriod OS
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
- 16 CH TVI / AHD 2.0 video input, 16 CH 1080P / 1080P lite / 720P 16 CH TVI / CVI / AHD video input
- 16 CH 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 recording
- 4 CH IPC 4MP / 3MP / 1080P / 960P / 720P recording (Up To 20 IPC)
- Adopt standard H.264 high profile compression format to get high-quality video at much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timer / motion / sensor
- Playback : 16 CH simultaneously playback
- Search: time slice, time, event ( manual, sensor, motion ), tag search
- Express and flexible backup via USB, network and so on
- Pentaplex: preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
- Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
- Multi-user online simultaneously
- Authorization management, log review and device status review
- HDMI 1080P output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QRCode scanning by mobile phone and PAD
- Powerful smart phone & Pad surveillance with iOS and Andriod OS
System Compression | H.264 High profile |
---|---|
Main Processor | Embedded Processor |
Operating System | Embedded Linux |
Video Compatibility | HD-TVI / AHD / HD-CVI / 960H / IP |
Max. Video Channels | 20CH |
Video In | BNC x 16 (TVI/AHD/CVI/960H) |
IP Camera Input | IPC x 4 (Max.12 IPC In) |
IPC Resolution | 4MP / 3MP / 1080P / 960P / 720P |
IPC Frame Rate | 4MP@30fps |
Video Interface | HDMI/VGA/CVBS(SPOT) |
Video Resolution | 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 |
Multi-Screen Display | N/A |
OSD | Yes |
Audio In | 16CH, RCA |
Audio Out | 1CH, RCA |
2 Way Audio | Take up channel one as an audio input |
Recording Resolution | 5MP, 4MP, 4MP lite, 3MP,1080P, 720P, WD1 |
Recording Frame Rate | 5MP@10fps, |
Recording Encode | N/A |
Recording Quality | 5 Level |
Recording Mode | Manual,sensor, motion, exception |
Recording File Management | Lock, Unlock |
Playback Channels | 16CH |
Playback Search | Time/Calendar Search, Event (motion) |
Playback Smart Search | Highlighted date and time to display the channel record |
Playback Function | Play, Pause, FF, FB; Digital zoom |
Alarm In | 16CH |
Alarm Out | 4CH |
Alarm Mode | Manual, sensor, motion, exception |
Trigger Events | Record, PTZ move,alarm out,e-mail, etc |
Network Bandwidth | IPC × 4 / 24Mbps |
Network Function | TCP/IP、PPPoE、DHCP、DNS、DDNS、UPnP、NTP、SMTP、ONVIF、GB28181 |
Network Max. Users | N/A |
Mobile | iPhone, Android |
Cellphone Function | Multi-screen surveillance (for certain model), record, snapshot, PTZ control, save the device list |
RS485 | RS485 x 2, connect to PTZ or keyboard |
USB | Rear: 1 x USB3.0, Front: 1 x USB2.0 |
remote | Optional |
Power Supply | AC 110 ~ 240V |
Power Consumption | <40W (without HDD) |
Internal HDD | 4 x SATA (up to 8TB capacity for each disk) |
e-SATA | N/A |
Operating Conditions | -10~50°C, 10%~90% (Humidity) |
Dimensions | 17.3" x 15.4" x 2.8" (440 x 390 x 70mm) |
- ManufacturerWEC
- Hard Drive #2I will install my own hard drive, 500GB HDD, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD
- Hard Drive #1I will install my own hard drive, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD
- Remote Login SupportNo Login Support Needed, FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
