2MP WDR Lighthunter IR Network Bullet Camera

UNV
SKU: IPC2322SB-HDZK-I0

1686028897443.pngHigh quality image with 2MP,1/2.8’’ CMOS sensor

1686028897022.png1920*1080@60fps in the main stream, deliver detailed live while 60fps making it smooth and closer to the real image

1686028897357.pngUltra 265, H.265, H.264, MJPEG

1686028896869.png5X optical zoom allows for closer viewing of subjects

1686028897231.pngSmart intrusion prevention, support false alarm filtering, include Cross Line, Intrusion, Enter Area, Leave Area detection

1686028897530.pngPeople Counting, support people flow counting and crowd density monitoring, suitable for different statistical scenarios

1686028896801.pngLighthunter product technology ensures ultra-high image quality in low illumination environment

1686028896943.pngUp to 120 dB Optical WDR (Wide Dynamic Range)

1686028897163.pngDC12V or PoE (IEEE 802.3af) power supply

1686028897093.pngWide voltage range of ±25% in DC

1686028897293.pngAudio 1 in and 1 out, Alarm 1 in and 1 out

 IPC2322SB-HDZK-I0
Camera
Sensor1/2.8", 2.0 megapixel, progressive scan, CMOS
Min. IlluminationColour:0.001 lux (F1.2, AGC ON)
0 lux with IR
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, 1 ~ 1/100000s
WDR120dB
S/N>52dB
Lens
Lens type2.7~13.5mm@F1.2, AF automatic focusing and motorized zoom lens
IrisFixed
Field of View (H)98.2°~30.6°
Field of View (V)53.3°~17.3°
Field of View (D)127.7°~37.6°
DORI
DORI DistanceLens (mm)Detect (m)Observe (m)Recognize (m)Identify (m)
2.770.9(232.5ft)28.4(93.0ft)14.2(46.5ft)7.1(23.3ft)
13.5247.5(812.0ft)99.0(324.8ft)49.5(162.4ft)24.8(81.2ft)
Illuminator
IR RangeUp to 50m (164 ft) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
Video
Video CompressionUltra 265, H.265, H.264, MJPEG
Frame RateMain Stream: 1080P (1920*1080),Max 60fps;
Sub Stream: 1080P (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps
Video Bit Rate128 Kbps~16 Mbps
ROIUp to 8 areas
Video streamTriple streams
OSDUp to 8 OSDs
Privacy MaskUp to 4 areas per scene
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
HLCSupport
BLCSupport
DefogDigital Defog
Intelligent
Smart intrusion preventionSupport false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Statistical AnalysisPeople counting, support people flow counting and crowd density monitoring
Events
Basic DetectionMotion detection, Audio detection, Tampering alarm
General FunctionWatermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio CompressionG.711U, G.711A
Audio Bitrate64 Kbps
Two-way AudioSupport
SuppressionSupport
Sampling Rate8KHZ
Storage
Edge StorageMicro SD, up to 256 GB
Network StorageANR,NAS(NFS)
Network
ProtocolsIPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API, SDK
User/HostUp to 32 users. 3 user levels: administrator, operator and common user
SecurityPassword protection, strong password, HTTPS encryption, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
ClientEZStation
EZLive
EZview
Web BrowserPlug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Interface
Audio I/O1/1
Alarm I/O1/1
Video output1 BNC(For debugging)
Network1 * RJ45 10M/100M Base-TX Ethernet
Certification
EMCCE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
SafetyCE LVD (EN 62368-1:2014+A11:2017)
CB (IEC 62368-1:2014)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
EnvironmentCE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtectionIP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
IK10 (IEC 62262:2002)
General
PowerDC12V(±25%), PoE(IEEE 802.3af)
Power consumption: Max 8W
Power InterfaceØ 5.5mm coaxial power plug
Dimensions (L x W x H)245.0x86.0x85.0mm (9.6’’x3.4’’x3.4’’)
Weight0.92kg(2.03lb)
Working Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Storage Environment-40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing)
Surge protection6KV
Reset buttonN/A


Datasheet of IPC2322SB-HDZK-I0

IPC2300 Series-Network Bullet Cameras Quick Guide-V1.01

Camera Installation Guide-V1.00

Network Cameras User Manual-V3.00


    • 12% less
    Market price:$610.00 save $71.00
  • $539.00
