CLEAR XVR832 32-Channel 1080p Universal Video Recorder (AHD,TVI,CVI & CVBS), 8 SATA, Up to 4 IP Cameras

CLEAR
SKU: CLR-XVR832
  • 32 BNC Video Inputs Supporting AHD, TVI, CVI and CVBS
  • H.264 Video Compression
  • Up to 1080p Recording Resolution
  • 1 HDMI, 1 VGA and 1 CVBS BNC Video Output
  • 8 SATA Interfaces for Internal Storage up to 8TB per HDD
  • 1 RJ-45 10/100/1000M Ethernet Interface
  • Supports NAT functionality and QRCode scanning for mobile device access
    • 60% less
    Market price:$1749.00 save $1050.00
  • $699.00

OR
  • 32 BNC Video Inputs Supporting AHD, TVI, CVI and CVBS
  • H.264 Video Compression
  • Up to 1080p Recording Resolution
  • 1 HDMI, 1 VGA and 1 CVBS BNC Video Output
  • 8 SATA Interfaces for Internal Storage up to 8TB per HDD
  • 1 RJ-45 10/100/1000M Ethernet Interface
  • Supports NAT functionality and QRCode scanning for mobile device access

32 Channel HD Over Coax Hybrid in addition to 4 Channel IP. Features the most powerful CPU in the CCTV market. Every Flux XVR32 features a Texas Instruments Quad Core Cortex A9 Processor. Compatible with all TVI, AHD, CVI and CVBS cameras. Full featured DVR platform includes VGA, HDMI, and a convenient analog BNC video output. Easy QR Code P2P setup. 8 SATA 4 Audio Inputs and 4 Alarm inputs.

Technical Specifications

CLR-XVR832

Video Input Interface

32 BNC Video Inputs

Video Input Signal

AHD, TVI, CVI, CVBS

IP Input Bandwidth

4 IP Cameras @ 24Mbps

Video Output Interface

1 HDMI, 1 VGA, 1 CVBS (BNC)

Display Resolution

1920 x 1080; 1280 x 1024

Audio Input Interface

16 Channel, RCA Audio Inputs

Audio Output Interface

1 Channel, RCA Audio Output

Two-way Audio

1 Channel, RCA Audio Input (Uses Channel 1 Audio Input)

Recording Resolution

1080p, 1080p lite, 720p WD1

Frame Rate

1080p: 15fps (NTSC) / 1080p lite, 720p, WD1: 30fps (NTSC)

Bit Rate

768Kbps - 8Mbps

IP Recording Rate

5MP@15fps; 4MP@20fps; 3MP / 1080p / 960p / 720p@30fps

Simultaneous Playback

Maximum 16 channels

Alarm Inputs

16 Channels

Relay Outputs

4 Channels

Network interface

1 x 10/100/1000M RJ-45 Ethernet Interface

Remote Connections

10 Remote Users Maximum

HDD Interfaces

8 SATA interfaces, maximum 8TB per HDD

Backup Media

External USB or Network Download

USB Interfaces

1 x USB2.0 (Front), 1 USB3.0 (Rear)

RS-485 Interface

2 Ports for Serial PTZ Contro

Power Supply

250W ATX Internal Power Supply

Power Consumption

<  40W (Without HDD)

Operating Environment

14° - 122°F, less than 90% Relative Humidity

Dimensions

16.9” x 17.7” x 3.5”

Weight (without HDD)

~22lbs



CRL-XVR832.pdf



    • SKU
      CLR-XVR832
    • Weight
      5 lbs
  • Manufacturer
    CLEAR
  • Recorder Type
    XVR
  • Hard Drive
    I will install my own hard drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive
  • Hard Drive #1
    I will install my own hard drive, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD
  • Hard Drive #2
    I Will Install My Own Hard Drive, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD
  • Remote Login Support
    No Login Support Needed, FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
