Titanium 4 CH Hybrid 4in 1 DVR ED8004H5-BN
Features
- 4 CH TVI / AHD/CVI 5MP/4MP/1080P/720P/WD1 video input
- 4 CH DVR supports 2 CH 5MP / 4MP / 3MP /1080P / 960P /720P IP video input
- Adopt standard H.265 high profile compression format to get high-quality video at the much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timed / motion / AI recording Playback : 4 CH simultaneously playback
- Search: time slice, time, event, tag search
- Express and flexible backup via USB, network, and so on
- Pentaplex: preview, record, playback, backup, and remote access
- DHCP, DDNS, PPPoE network protocol
- Remote control via Web or CMS: preview, playback, backup, PTZ, and configuration
- Dual stream technology for local storage with high definition, remote network transmission, and remote surveillance with mobile device
- Authorization management, log review and device status review
- Support 1080P output, true high-resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QRCode scanning by mobile phones
- Powerful mobile surveillance by smartphones with iOS and Andriod OS
| System Compression | H.264/H.265 |
|---|---|
| Main Processor | Embedded Processor |
| Operating System | Embedded Linux |
| Video Compatibility | TVI/AHD/CVI : 5MP/4MP/1080P/720P/WD1 |
| Max. Video Channels | 6CH(Upto 4CH BNC/6CH IP) |
| Video Input | Total Input 6CH |
| IP Camera Input | 2CH. up to 6CH. |
| IPC Resolution | Up to 5MP |
| IPC Frame Rate | 5MP@25fps |
| Video Resolution | HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 BNC × 1 : CVBS ( used as the main or spot output) |
| Multi-Screen Display | 1/4/6/9 |
| OSD | Yes |
| Audio In | 1-ch, RCA |
| Audio Out | RCA × 1 (linear, 600Ω) |
| 2 Way Audio | Take up channel one audio input |
| Recording Resolution | 5MP Lite/4MP Lite/1080P/1080P Lite/720P/WD1 |
| Recording Frame Rate | Analog Channel: 5MP Lite :10fps; 4MP Lite/1080P : 12fps (PAL)/15fps (NTSC);1080P Lite/720P/WD1 : 25fps (PAL)/30fps (NTSC) IP Channel: 25fps (PAL)/30fps (NTSC) |
| Recording Mode | Manual, timer, motion, smart event |
| Playback Channels | 4-ch |
| Playback Search | Time/Calendar Search, Event (motion) |
| Playback Smart Search | Highlighted date and time to display the channel record |
| Playback Function | Play, Pause, FF, FB; Digital zoom |
| Alarm Mode | Manual, sensor, motion, exception, smart events |
| Network Bandwidth | Incoming Bandwidth: 16Mbps, Outgoing Bandwidth: 40Mbps |
| Network Max. Users | Max. 5 users access |
| Mobile | iPhone, Android |
| RS485 | RS 485 × 1 (half-duplex) |
| USB | USB 2.0 × 2 ( in the rear panel ) |
| Remote Connections | Optional |
| Power Supply | DC12V / 1.5A |
| Power Consumption | ≤5W( without HDD) |
| Internal HDD | SATA × 1, up to 10TB |
| Operating Conditions | -10~50°C, 10%~90% (humidity) |
| Dimensions | 255× 222× 42( W × D × H ) |
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
The Titanium 4 CH Hybrid 4in 1 DVR ED8004H5-BN is a professional-grade digital video recorder designed for small to medium-sized businesses and organizations. It supports up to 4 analog or IP cameras, providing clear and detailed video footage for surveillance purposes.
One of the key features of this digital video recorder is its hybrid technology, which enables it to support four different types of video signals including HDCVI, AHD, TVI, and CVBS cameras. It also supports H.265+ video compression technology, which can significantly reduce storage and bandwidth usage without compromising video quality.
The ED8004H5-BN has a user-friendly interface, making it easy to set up and configure your security system. It also supports remote viewing through a web browser or mobile app, enabling you to monitor your security cameras from anywhere with an internet connection.
In addition, this digital video recorder offers various security features, such as password protection and IP address filtering, to ensure your system is secure from unauthorized access. It also supports intelligent video analytics, such as motion detection and tamper detection, which can trigger alerts and notifications when unusual activities are detected.
This digital video recorder is housed in a compact and durable chassis, making it easy to install and integrate with other security equipment. It also features a powerful processing unit, which ensures smooth and reliable video recording and playback.
Overall, the Titanium 4 CH Hybrid 4in 1 DVR ED8004H5-BN is a professional-grade video surveillance solution that offers advanced features and capabilities for small to medium-sized businesses and organizations. Its hybrid technology, user-friendly interface, and remote viewing capabilities make it a versatile and easy-to-use solution for a wide range of surveillance applications. With its powerful processing unit and security features, it provides reliable and efficient video surveillance for any security system.
