IMAXCAMPRO HNC3V341R-IR-ZS | 4MP Eyeball Network Motorized Security Camera

iMaxCamPro
SKU: WECIHNC3V341R-IR-ZS

Features

  • 1/2.7” 5Megapixel progressive CMOS
  • H.265& H.264 dual-stream encoding
  • 15fps@5M(2592×1944) &25/30fps@3M(2304×1296)
  • WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
  • Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
  • 2.8 mm fixed lens
  • Max IR LEDs Length 30m (98FT)
  • IP67, IK10, PoE
More Information
Image Sensor1/2.7” 5Megapixel progresive CMOS
Image Size2592(H)x1944(V)
RAM/ROM512MB/32MB
Electronic ShutterAuto/Manual, 1/3~1/100000s
Minimum Illumination0.03Lux/F2.0( Color,1/3s,30IRE)
0.3Lux/2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
S/N RatioMore than 50dB
IR LEDs24
Smart IRSupport
IR DistanceDistance up to 30m(98ft)
IR On/Off ControlAuto/ Manual
Focal Length2.8mm
Angle of ViewH:96°/78°, V:70°/58°
Max. ApertureF2.0/F2.0
Optical ZoomN/A
Close Focus DistanceN/A
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
63(207ft)
25(82ft)
13(43ft)
6(20ft)
Pan / Tilt / RotationPan:0° ~355° ;Tilt:0° ~64° ;Rotation:0° ~355°
Video CompressionH.265/H.264H/MJPEG(Sub Stream)
Streaming Capability2 Streams
Video Resolution

5M(2592×1944)/4M(2688x1520)/3M(2304×1296 / 2 048x1536)/1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/VGA(640×480)/ CIF(352×288/352×240)

Video Frame Rate

Main Strwam: 5M(1 ~ 15fps)/3M(1 ~ 25/30fps)
Sub Stream: D1(1 ~ 25/30fps)

Video BitrateH.265: 12K ~ 8448Kbps
H.264: 32K ~ 10240Kbps
Day / NightAuto(ICR) / Color / B/W
BLC ModeBLC / HLC / WDR(120dB)
White BalanceAuto/Natural/Street Lamp/Outdoor/Manual
Gain ControlAuto/Manual
Digital Noise Reduction3D DNR
Motion DetectionOff / On (4 Zone, Rectangle)
Region of InterestOff / On (4 Zone)
Electronic Image Stabilization (EIS)N/A
DefogN/A
Digital Zoom16x
Flip0°/90°/180°/270°
MirrorOff / On
Privacy MaskingOff / On (4 Area, Rectangle)
Audio CompressionN/A
IPC AlarmN/A
Alarm InN/A
Alarm OutN/A
AI Perimeter ProtectionTripwire, Intrusion
Advanced AI FunctionsN/A
EthernetRJ-45 (10/100Base-T)
Network ProtocolHTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;
FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP;
NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS
Network InteroperabilityONVIF Profile S&G, API
Streaming MethodUnicast / Multicast
Network Max. Users20 Users
StorageNAS Local PC for instant recording
Storage CardN/A
Web ViewerIE, Chrome, Firefox, Safari
Management SoftwareSmart PSS, DSS,Easy4ip
MobileiPhone, Android
Video OutputN/A
CertificationsCE (EN 60950:2000)
UL:UL60950-1
FCC: FCC Part 15 Subpart B
Audio InterfaceN/A
RS485N/A
Power SupplyDC12V PoE(802.3af)(Class 0)
Power Consumption<6W
Operating Temperature-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Storage Temperature-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH
Ingress ProtectionIP67
Dimensions109.9mm × 81mm (4.33" x 3.19")
WeightNet Weight 0.34Kg (0.75lb) Gross Weight 0.47Kg (1.04lb)
    • 50% less
    Market price:$596.00 save $298.00
  • $298.00

OR
