Features

  • 1/3-in. 4 MP Progressive Scan CMOS
  • Powerful 30x Optical Zoom
  • H.265 and H.264 Video Compression Encoding
  • 4 MP / 3 MP @ 30 fps and 1080p @ 30/60 fps
  • True Wide Dynamic Range
  • Auto-tracking and Intelligent Video System (IVS)
  • Max. IR distance up to 100 m (328 ft)
  • IP66 Environmental Protection Rating
  • PoE+ Support

EOL: End of Life

EOL Date: 4/30/2017

Suggested Replacement


CAD Images

  • 59 copy.jpg

Compression

FOV

  • Camera Height: 10m
    Focal Length: 4.5mm
    Target Horizontal Dist: 83.1m

  • Camera Height: 10m
    Focal Length: 135mm
    Target Horizontal Dist: 2511.1m

Firmware

You can update your device with the IP Firmware Toolkit.

Firmware Update Download

Intelligent Features

  • Face Detect

  • Tripwire

  • Intrusion

  • Abandoned/Missing


Specifications

Camera
Image Sensor1/3-in. CMOS
Effective Pixels2592(H) x 1520(V), 4 MP
RAM/ROM1024 MB / 128 MB
Scanning SystemProgressive
Minimum IlluminationColor: 0.05 Lux @ F1.6

0 Lux @ F1.6 (IR on)
S/N RatioMore than 55 dB
IR DistanceDistance up to 100.0 m (328.10 ft)
IR On/Off ControlAuto/Manual
IR LEDsFour (4)
Lens
Focal Length4.5 mm to 135 mm
Max. ApertureF1.6 to F4.4
Angle of ViewHorizontal: 2.2° to 60°
Optical Zoom30x
Focus ControlAuto/Manual
Close Focus Distance100 mm to 1000 mm
PTZ
Pan/Tilt RangePan: 0° to 360° endless

Tilt: -15° to 90°, Auto Flip 180°
Manual Control SpeedPan: 0.1° to 300° /s

Tilt: 0.1° to 200° /s
Preset SpeedPan: 400° /s

Tilt: 300° /s
Presets300
PTZ Mode5 Pattern, 8 Tour, Auto Pan, Auto Scan
Speed SetupHuman-oriented Focal Length, Speed Adaptation
Power up ActionAuto restore to previous PTZ and lens status after power failure
Idle MotionActivate Preset, Scan, Tour, or Pattern if there is no command in the specified period
ProtocolDH-SD
Intelligence
Auto TrackingSupport
IVSTripwire, Intrusion, Abandoned/Missing Object, Face Detection
Video
CompressionH.265, H.264, MJPEG
Streaming CapabilityThree (3) Streams
Resolution4 MP (2592 x 1520), 3 MP (2304 x 1296),

1080p (1920 x 1080), 720p (1280 x 720),

D1 (704 x 480), CIF (352 x 240)


Frame RateMain Stream: 4 MP, 3 MP, 1.3 MP, 720p (1 to 30 fps) or 1080p (1 to 60 fps)

Sub Stream 1: D1, CIF (1 to 30 fps)

Sub Stream 2: 1080p, 1.3 MP, 720p (1 to 30 fps)
Bit Rate ControlCBR, VBR
Bit RateH.265/H.264: 448 K to 8192 Kbps

MJPEG: 5120 K to 10240 Kbps
Day/NightAuto (ICR), Color, B/W
Backlight CompensationBLC, HLC, WDR (120 dB)
White BalanceAuto, ATW, Indoor, Outdoor, Manual
Gain ControlAuto / Manual
Noise ReductionUltra DNR (2D/3D)
Advanced FeaturesMotion Detection, Region of Interest,

Electronic Image Stabilization (EIS), Defog
Digital Zoom16x
Flip180°
Privacy MaskingUp to 24 areas
Audio
CompressionG.711a, G.711Mu, AAC, G.722, G.726, G.729, MPEG2-L2
Network
EthernetRJ-45 (10/100 Base-T)
ProtocolIPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP,

ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP,

DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
InteroperabilityONVIF, PSIA, CGI
Streaming MethodUnicast / Multicast
Max. User Access20 users
Edge StorageNAS (Network Attached Storage)

Local PC for instant recording, 128 GB
Web ViewerIE 10, Safari
Management SoftwareSmart PSS, DSS
Mobile Operating SystemIOS, Android, Windows
Certifications
CEEN 55032

EN 55024

EN 50130-4
ULUL: UL60950-1 + CAN/CSA C22.2, No.60950-1
Electromagnetic Compatibility (EMC)FCC Part 15 Subpart B

ANSI C63.4-2014
Interface
Audio InterfaceIn: One (1) Channel

Out: One (1) Channel
AlarmIn: Two (2) Channels

Out: One (1) Channel
Electrical
Power SupplyAC24V, 3A (±10%), PoE+ (802.3at)
Power Consumption13 W, 23 W with IR on
Environmental
Operating Conditions-40°C to 70°C (-40°F to +158°F), Less than 90% RH
Ingress ProtectionIP66
Construction
CasingMetal
DimensionsΦ186.0 mm x 309.0 mm (Φ7.32 in. x  12.17 in.)
Net Weight3.50 kg (7.72 lb)
Gross Weight6.80 kg (14.99 lb)
