Geovision GV-BX5700-8F H.265 5MP 2.95mm, D/N Box cam, PoE 115-BX5700-8F0
- 1/1.8" progressive scan low lux CMOS
- Min. illumination at 0.03 lux
- Dual streams from H.265, H.264 and MJPEG
- Up to 30 fps at 2592 x 1944
- P-Iris for auto iris adjustment
- Built-in / external microphone
- Two-way audio
- One sensor input and alarm output
- TV-out support
- Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I) for local storage
- Recording assigned by GV-Edge Recording Manager (Windows, Mac version)
- Mini USB slot for WiFi Adapter or USB hard drive
- Wide Dynamic Range (WDR)
- 3D noise reduction
- Smart streaming
- Defog
- Motion detection
- Tampering alarm
- Privacy mask
- IP address filtering
- DC 12V / PoE (IEEE 802.3af)
- Day and night function (with removable IR-cut filter)
- Varifocal megapixel lens
- Supports iPhone, iPad, Android & 3GPP
- 31 languages on Web interface
- ONVIF (Profile S) conformant
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
The GeoVision GV-BX5700-8F H.265 5MP 2.95mm D/N Box Cam, which is a high-performance surveillance camera with a 5-megapixel resolution and advanced features such as H.265 video compression and day/night switching for 24/7 surveillance capabilities. It has a fixed 2.95mm lens that allows for a wide viewing angle, and it also features super low lux capabilities for clear video in low-light conditions.
This camera supports Power over Ethernet (PoE) for easy installation and setup, and it includes advanced features such as motion detection, tampering alarm, and privacy mask. The camera can be accessed remotely through a web browser or a mobile app for convenient viewing and control.
The GeoVision GV-BX5700-8F H.265 5MP 2.95mm D/N Box Cam is suitable for a variety of indoor and outdoor surveillance applications, including homes, businesses, and public spaces. Its advanced features and high-quality imaging capabilities make it a reliable and effective surveillance solution.
Camera packaging contents:
- H.265 Box Camera
- Terminal Block (2-Pin and 3-Pin)
- Fixed Focal or Varifocal Megapixel Lens
- Six Lens Rings (only for Varifocal Lens)
- Video Out Wire
- Camera Holder
- Holder Screw x 2
- GV-IPCAM Software DVD
- GV-Software DVD
- Warranty Card
- 1/1.8" progressive scan low lux CMOS
- Min. illumination at 0.03 lux
- Dual streams from H.265, H.264 and MJPEG
- Up to 30 fps at 2592 x 1944
- P-Iris for auto iris adjustment
- Built-in / external microphone
- Two-way audio
- One sensor input and alarm output
- TV-out support
- Built-in micro SD card slot (SD/SDHC/SDXC/UHS-I) for local storage
- Recording assigned by GV-Edge Recording Manager (Windows, Mac version)
- Mini USB slot for WiFi Adapter or USB hard drive
- Wide Dynamic Range (WDR)
- 3D noise reduction
- Smart streaming
- Defog
- Motion detection
- Tampering alarm
- Privacy mask
- IP address filtering
- DC 12V / PoE (IEEE 802.3af)
- Day and night function (with removable IR-cut filter)
- Varifocal megapixel lens
- Supports iPhone, iPad, Android & 3GPP
- 31 languages on Web interface
- ONVIF (Profile S) conformant
Rear Panel
Dimensions
Standard
Wall Mount
Ceiling Mount
Desk Mount
Optional
GV-Housing102
Wall Mount
Convex Corner Mount
Concave Corner Mount
Pole Mount
Wall Mount
Convex Corner Mount
Concave Corner Mount
Pole Mount
GV-IP Camera Bandwidth and Recording Size Calculator
[ebook on iBooks Store] Quick Start Guide
[ebook on Google Play] Quick Start Guide
| Item No. (Sales Part No.) | Description |
|---|---|
| 140-WFUSB-000 | GV-WiFi Adapter |
| Model No | Name | Details | |
| GV-Mount300 / GV-Mount300-1 | Convex Corner Adapter Kit | Dimensions: 238.6 x 409.5 mm (9.4 x 16.1") Weight: 4.27 kg (9.41 lb) | |
| GV-Mount310 / GV-Mount310-1 | Concave Corner Adapter Kit | Dimensions: 123.3 x 393.1 mm (4.9 x 15.5") Weight: 2.96 kg (6.53 lb) | |
| GV-Mount400 / GV-Mount400-1 | Pole Mount Bracket Kit (Ø 4 ~ 6") | Bracket: 241 x 161 mm (9.5 x 6.3") Weight: 1.70 kg (3.75 lb) Steel Strap Diameter: Ø 4 ~ 6" | |
| GV-Mount410 / GV-Mount410-1 | Pole Mount Bracket Kit (Ø 6 ~ 7.5") | Bracket: 241 x 161 mm (9.5 x 6.3") Weight: 1.70 kg (3.75 lb) Steel Strap Diameter: Ø 6 ~ 7.5" | |
| GV-Housing102 (not supported by GV-BX5700-8F) | Housing Box (with heater and fan) | Dimensions: 406 x 145 x 109 mm (16 x 5.7 x 4.3") Weight: 4.69 kg (10.34 lb) (including Supporting Tube) Start-up Temperature: -30°C ~ 50°C (-22°F ~ 122°F) Operation Temperature: ‐40°C ~ 50°C (-40°F ~ 122°F) Heater: 15°C (59°F) On / 25°C (77°F) Off Fan: 35°C (95°F) On / 25°C (77°F) Off Power board: 24V AC / 12V DC input | |
| GV-Housing103 (not supported by GV-BX5700-8F) | Housing Box (with IR) | Dimensions: 404 x 128 x 257 mm (15.91 x 5.04 x 10.12") Weight: 7 kg (15.43 lb) Start-up Temperature: ‐20°C ~ 50°C (‐4°F ~ 122°F) Operation Temperature: ‐30°C ~ 50°C (‐22°F ~ 122°F) IR: 6 IR LEDs with up to 60m (196.85ft) IR effective distance Power: 12V DC, 1A input | |
| GV-PA191 PoE Adapter | Power over Ethernet (PoE) Adapter | The GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable. | |
| GV-POE Switch | The GV-POE Switch is designed to provide power along with network connection for IP devices. The GV-POE Switch is available in various models with different numbers and types of ports. | ||
| Power Adapter | Contact your sales representative for the countries and areas supported. | ||
| GV-Relay V2 | The GV-Relay V2 is designed to expand the voltage load of GV IP devices. It provides 4 relay outputs, and each can be set as normally open (NO) or normally closed (NC) independently as per your requirement. | ||
| GV-WiFi Adaptor V2 | Weight: 0.01 kg (0.02 lb) Dimensions (H x W x D): 15 x 15 x 155 mm (0.59 x 0.59 x 6.10") Supplied with Mini USB to standard USB adapter | ||
- ManufacturerGeovision
- Camera TypeBox
- Camera SignalIP
- Camera Resolution5 Megapixel
- Optical ZoomVarifocal
- UPC4712896444450
- Shipping Lead TimeShips Same Day
- Remote Login SupportNo Login Support Needed, 1 Time FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
