16CH 2SATA 8MP Penta-brid 4K XVR

iMaxCamPro
SKU: WEC502A16-4KLI3
    • 22% less
    Market price:$897.00 save $199.00
  • $698.00

OR
16CH Digital Video Recorder,Max. 32CH Security Cameras (Upto 16CH BNC/32CH IP),4K@7FPS,5MP@12FPS,4K@15FPS Liveview, 2ch FR,2ch PP,16ch SMD+,AI coding,HDMI/VGA,Audio,2 SATA

· H.265+/H.265 dual-stream video compression
· Supports HDCVI/AHD/TVI/CVBS/IP video inputs
· Max 32 channels IP camera inputs, each channel up to 8MP; Max
128 Mbps incoming bandwidth
· Perimeter Protection and SMD Plus
· Up to 2 channels video stream (analog channel ) human face recognition
· IoT & POS functionalities

More Information
System CompressionH.265+/H.265
Main ProcessorEmbedded Processor
Operating SystemEmbedded Linux
OSDNo
Recording Resolution4K, 6MP, 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF
Bit Rate32 Kbps–6144 Kbps Per Channel
Recording ModeManual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Record Interval1 – 60 min (default: 60 min), Pre-record: 1 s–30 s, Post- record: 10 s–300 s
Playback Channels1/4/9/16
Playback SearchTime /Date, Alarm, MD and Exact Search (accurate to second)
Playback FunctionPlay, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
Backup ModeUSB Device/Network
Audio In4/1, RCA
Audio Out4/1, RCA
2 Way AudioReuse audio in/out, RCA
Trigger EventsRecording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
Video DetectionMotion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis
Alarm In16
Alarm Relay Output3
Network Interface1 RJ-45 Port (1000 MB)
Network Function

HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, 3G/4G, SNMP,
UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter,
PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports
Dahua IP camera, DVR, NVS, etc.)

Network Max. Users128 users
MobileiPhone, Android
RS4851 Port, for PTZ Control
USB2 USB Ports (1 USB 2.0 , 1 USB 3.0)
RS232N/A
Power SupplyDC 12V/5A
Power Consumption<15W
e-SATAN/A
Operating Conditions-10°C to +55°C (+14°F to +131°F), 0–90% RH
Dimensions1U, 375 mm × 288 mm × 53 mm (14.76'' × 11.30'' × 2.09'')
Weight(without HDD) 1.9 kg (4.2 lb) Gross Weight 3.2 kg (7.0 lb)
    • SKU
      WEC502A16-4KLI3
    • Weight
      7.05 lbs
  • Manufacturer
    iMaxCamPro
  • Hard Drive #1
    I will install my own hard drive, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD
  • Remote Login Support
    No Login Support Needed, FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
