        4K Starlight HDCVI IR Bullet Camera

        SKU: WECHCC3240E-IR/36
        WEC
        SKU: WECHCC3240E-IR/36
        • Starlight, 120dB True WDR, 3DNR
        • Max. 4K resolution
        • HD/SD switchable
        • Audio in interface, built-in mic
        • 6mm/3.6mm fixed lense
        • Max. IR length 80m, Smart IR
        • IP67, DC12V±30%
          • 50% less
          Market price:$280.00 save $140.00
        • $140.00

        OR

        PRODUCT FEATURES

        • Starlight, 120dB True WDR, 3DNR
        • Max. 4K resolution
        • HD/SD switchable
        • Audio in interface, built-in mic
        • 6mm/3.6mm fixed lense
        • Max. IR length 80m, Smart IR
        • IP67, DC12V±30%
        Image Sensor1/2" CMOS
        Image Size3840(H)×2160(V), 8MP
        Electronic ShutterPAL: 1/4s~1/100,000s NTSC: 1/3s~1/100,000s
        Minimum Illumination0.005Lux/F1.6, 30IRE, 0Lux IR on
        S/N RatioMore then 65dB
        IR LEDs4
        Smart IRSupport
        IR DistanceUp to 80m (262feet)
        IR On/Off ControlAuto / Manual
        Focal Length6mm/3.6mm
        Angle of ViewH: 55°/87H°
        Max. ApertureF1.6
        Optical ZoomN/A
        Close Focus Distance240.2''/98.43''
        DORI Distance
         DORI DefinitionDistance
        6mm3.6mm
        Detec25px/m (8px/ft)164m(ft)104m(ft)
        Observe63px/m (19px/ft)66m(ft)42m(ft)
        Recognize125px/m (38px/ft)33m(ft)21m(ft)
        Identify250px/m (76px/ft)16m(ft)10m(ft)
        Pan / Tilt / RotationPan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360°
        Video CompressionN/A
        Video Resolution8MP (3840×2160)
        Video Frame Rate15fps@4K, 20fps@6MP, 25/30fps@4MP
        Day / NightAuto (ICR) / Manual
        BLC ModeBLC / HLC / WDR (120dB)
        White BalanceAuto / Manual
        Gain ControlAGC
        Digital Noise Reduction2D/3D
        Motion DetectionN/A
        Audio CompressionN/A
        Video Output1-channel BNC high definition video output / CVBS video output (DIP switch)
        CertificationsCE (EN55032, EN55024, EN50130-4)
        FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
        UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
        Audio Interface1ch in & Built-in Mic
        RS485N/A
        Alarm InN/A
        Alarm OutN/A
        Power Supply12V DC ±30%
        Power ConsumptionMax 12.5W (12V DC, IR on)
        Operating Temperature-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH; Start up should be done at above -30°C (-22°F)
        Storage Temperature-30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
        Ingress ProtectionIP67
        Dimensions244.1mm×90.4mm×90.4mm (9.61"×3.56"×3.56")
        WeightNet Weight 0.42kg (0.93lb) Gross Weight 0.53kg (1.17lb)
