- 68% less
iMaxCamPro NVR301HS-04/P-4KS2 | 4 Channel Compact 1U 4PoE 4K&H.265 Lite Network Recorder MNR8041X-4
SKU: WEC301HS-04/P-4KS24 Channel Compact 1U 4PoE 4K&H.265 Lite Network Video Recorder, H.265/H.264, Two-way talk 1-in/1-out, 30fps@4K, 1 HDMI, 1 VGA, 4CH playback, 1 RJ-45, 4 PoE ports, 1 SATA, 2 USB ports, DC48V/1.5A
Features
- H.265/H.264 codec decoding
- Max 80Mbps Incoming Bandwidth
- Up to 8MP Resolution for Preview and Playback
- HDMI/VGA simultaneous video output
- Support IPC UPnP, 4PoE ports
- Support ANR technology to enhance the storage reliability when the network breaks down
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
4 Channel Compact 1U 4PoE 4K&H.265 Lite Network Video Recorder, H.265/H.264, Two-way talk 1-in/1-out, 30fps@4K, 1 HDMI, 1 VGA, 4CH playback, 1 RJ-45, 4 PoE ports, 1 SATA, 2 USB ports, DC48V/1.5A
Features
- H.265/H.264 codec decoding
- Max 80Mbps Incoming Bandwidth
- Up to 8MP Resolution for Preview and Playback
- HDMI/VGA simultaneous video output
- Support IPC UPnP, 4PoE ports
- Support ANR technology to enhance the storage reliability when the network breaks down
System Compression | H.265/ H.264 |
---|---|
Main Processor | Embedded Processor |
Operating System | Embedded Linux |
Video Output | 1 HDMI, 1 VGA |
Video Resolution | HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
IP Camera Input | 4CH |
Display Split | 4/8 Channel |
Recording Resolution | 8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc. |
Recording Rate | N/A |
Bit Rate | 16Kbps ~ 20Mbps Per Channel |
Recording Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop |
Record Interval | 1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
Audio In | 1CH |
Audio Out | 1CH |
2 Way Audio | 1 Channel Input, 1 Channel Output, RCA |
Alarm In | N/A |
Alarm Out | N/A |
Trigger Events | Recording, PTZ, Tour, Video Push, Email, Snapshot, Buzzer and Screen Tips |
Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
Alarm Relay Output | N/A |
Playback Channels | 1/4 |
Playback Search | Time/Calendar Search, Event (motion) |
Playback Function | Play, Pause, FF, FB; Digital zoom |
Backup Mode | USB Device/Network |
Performance | Max 12 face pictures /sec processing 2 channel video stream face recognition 8 channel picture stream face recognition ( with FD camera) |
Stranger Mode | Detect strangers' faces(not in device's face database). Similarity threshold can be set manually. |
AI Search | Up to 8 target face images search at same time, similarity threshold can be set for each target face image. |
Database Management | Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, certificate No., countries®ions and state can be added to each face picture. |
Database Application | Each database can be applied to video channels independently. |
Network Interface | 1 RJ-45 Port (10/100Mbps) |
PoE Ports | 4 Ports(IEEE802.3at/af) |
Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, SNMP, IP Search (Support Dahua IP camera, DVR, NVS, etc.), Easy4ip |
Network Max. Users | 128 users |
Mobile | iPhone, Android |
USB | 2 ports (1 Rear USB2.0, 1 Front USB2.0) |
RS485 | N/A |
RS232 | N/A |
Internal HDD | 1 SATA III Port, Up to 6 TB capacity for each HDD |
e-SATA | N/A |
Power Supply | DC48V/1.5A |
Power Consumption | NVR: <7.5W (Without HDD) PoE: Max 25.5W for single port, 50W in total |
Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
Dimensions | Compact 1U, 260mm×224.9mm×47.6mm (10.2" x 8.9" x 1.9") |
Weight | Net Weight: 0.8kg (1.76 lb) (without HDD) Gross Weight: 1.6kg(3.53 lb)(without HDD) |
- ManufactureriMaxCamPro
- Number of Channels4 Channels
- Recorder TypeNVR
- Hard Drive #1I will install my own hard drive, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD, 6TB HDD
- Remote Login SupportNo Login Support Needed, FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
