This is a 4K Ultra HD Vandal-resistant Fisheye Fixed Dome Camera. Infrared night vision allows the security camera to see up to 65 feet in total darkness. The surveillance camera also comes equipped with 3D DNR (Digital Noise Reduction) and has a built-in microphone & speaker--two way talk is even supported with this. It is small and discreet but durable, with an IK10 and an IP66 rating.

This 4K Ultra HD Vandal-resistant Fisheye Fixed Dome Camerais a smart functioning security camera. It shoots footage in resolution of 4000 x 3000 pixels. With Infrared night vision, the camera allows you to maintain perfect vision in total darkness in an area as wide and big as 65 feet. This vandal resistant fisheye security camera comes equipped with a Digital Noise Reduction (3D DNR) feature. Moreover it has a built in speaker and microphone. Dual sided conversations can be held with this camera. It’s durable with IP66 rating. It also can operate under severe temperatures such as -22°F to 140°F (-30°C to 60°C). It also has "Smart IR" which will adjust based on the situation to give you an optimal image.

Optics

• Ultra wide angle lens, 360°panoramic image
• Embedded infrared light, 360°fill-in light, Up to 20 m (65 ft) IR distance
• 3D DNR (Digital Noise Reduction)

Compression

• 4K, Max. 4000 * 3000 resolution
• Built-in microphone & speaker, two-way talk supported
• Sextuple streams
• ROI (Region of Interest)
• Distortion correction supported

The UN IPC868ER-VF18-B from UNV Uniview is a high-performance fisheye fixed dome camera designed for professional surveillance applications. With its 4K Ultra HD resolution and advanced features, it is capable of providing excellent coverage and detail in a wide range of environments.

One of the standout features of this camera is its 180-degree panoramic view. With a fisheye lens that covers a wide area, this camera is ideal for monitoring large spaces such as warehouses, airports, and parking lots. It also has a built-in de-warping function that allows you to correct the distortion in the image, providing a more natural view of the scene.

The UN IPC868ER-VF18-B also features vandal-resistant housing that protects it from physical damage. It is designed to withstand harsh environments, making it an ideal choice for outdoor surveillance. The camera is also rated for IK10 impact resistance, which means it can withstand impact from objects weighing up to 5kg.

In addition to its robust construction, the UN IPC868ER-VF18-B features advanced imaging technologies. It has true WDR (Wide Dynamic Range) technology that provides clear images in challenging lighting conditions. It also has 3D DNR (Digital Noise Reduction) technology, which helps to eliminate noise from images, resulting in clearer video footage.

The camera supports Power over Ethernet (PoE), which simplifies installation and reduces cabling requirements. It also supports ONVIF, which makes it easy to integrate with other surveillance systems.

Overall, the UN IPC868ER-VF18-B is a high-performance fisheye fixed dome camera that provides excellent coverage and detail in a wide range of environments. With its advanced features and robust construction, it is an ideal choice for professional surveillance applications.

World Eye Cam has a free consultation and system design system that you can make good use of by calling us on (1-888-211-2288) or shoot us an email.

This is a 4K Ultra HD Vandal-resistant Fisheye Fixed Dome Camera. Infrared night vision allows the security camera to see up to 65 feet in total darkness. The surveillance camera also comes equipped with 3D DNR (Digital Noise Reduction) and has a built-in microphone & speaker--two way talk is even supported with this. It is small and discreet but durable, with an IP10 and an IP66 rating.

Product Features

Optics

• Ultra wide angle lens, 360°panoramic image
• Embedded infrared light, 360°fill-in light, Up to 20 m (65 ft) IR distance
• 3D DNR (Digital Noise Reduction)

Compression

• 4K, Max. 4000 * 3000 resolution
• Ultra 265, H.265, H.264, MJPEG
• Built-in microphone & speaker, two-way talk supported
• ROI (Region of Interest)
• Distortion correction supported

Network

• ONVIF Conformance

Structure

• Support PoE power supply
• Wide temperature range: -30°C to 60°C (-22°F to 140°F)
• Wide voltage range of ±25%
• IK10
• IP66
