N84BG44I


USA/IPCamera/Ultra/N84BG44I

N84BG44I

float

float

Features

  • 1/2.5-in. 8 MP Progressive Scan CMOS
  • Smart H.265+ and H.264 Triple-stream Encoding
  • 15 fps @ 4K/8 MP (3840 x 2160) and 30 fps @ 3 MP (2304 x 1296)
  • Smart Detection Supported
  • Digital WDR and Day/Night IR Cut Filter
  • 4 mm Fixed Lens
  • Max. IR LED Length 50 m (164 ft)
  • Built-in Microphone
  • Micro SD Memory, IP67, PoE

Compression

FOV

  • Camera Height: 10m
    Focal Length: 4mm
    Target Horizontal Dist: 63.1m

Firmware

You can update your device with the IP Firmware Toolkit.

Firmware Update Instructions

Firmware Update Download

Firmware Changelog

  • Build Date: 1/05/17
  • English, French, Spanish optional,English default
  • NTSC


Intelligent Features

  • Tripwire

  • Intrusion

  • Abandoned/Missing

Compatible Accessories

Compatible Accessories
Accessories Combo 1PFA139PFA139
Accessories Combo 2PFA139PFA139PFA150PFA150
Accessories Combo 3PFB204WPFB204W
Accessories Combo 4PFB204WPFB204WPFA152PFA152
Accessories Combo 5PFA121PFA121
Accessories Combo 6PFA121PFA121PFA151PFA151
Accessories Combo 7PFA121PFA121PFA150PFA150

Specifications

Camera
Image Sensor1/2.5-in. 8 MP Progressive Scan CMOS
Effective Pixels3840(H) x 2160(V)
RAM/ROM512 MB / 32 MB
Scanning SystemProgressive
Minimum IlluminationColor: 0.05 lux at F1.6
 B/W: 0 lux at F1.6 (IR on)
S/N RatioMore than 50 dB
IR DistanceDistance up to 50 m (164.04 ft)
IR On/Off ControlAuto / Manual
IR LEDsOne (1)
Lens
Lens TypeFixed
Mount TypeBoard-in
Focal Length4 mm
Max. ApertureF1.6
Angle of ViewHorizontal: 87°
 Vertical: 48°
Focus ControlFixed
Pan/Tilt/Rotation
RangePan: 0˚ to 360˚
 Tilt: 0˚ to 78˚
 Rotation: 0˚ to 360˚
Intelligence
IVS (optional)Tripwire, Intrusion, Abandoned/Missing Object
Advanced Intelligent  FunctionsFace Detection
Video
CompressionSmart H.265+ / H.265 / Smart H.264+ / H.264
Streaming CapabilityThree (3) Streams
Resolution4K/8 MP (3840 x 2160), 6 MP (3072 x 2048),
 5 MP (2560 x 1920), 3 MP (2048 x 1536),
 3 MP (2304 x 1296), 1080p (1920 x 1080),
 1.3 MP (1280 x 960), 720p (1280 x 720),
 D1 (704 x 480), VGA (640 x 480), CIF (352 x 240)
Frame RateMain Stream: 4K/8 MP (1 to 15 fps) or
                         3 MP (1 to 30 fps)
 Sub Stream 1 : D1 (1 to 30 fps)
 Sub Stream 2: 720p (1 to 30 fps)
Bit Rate ControlCBR/VBR
Bit RateH.264: 24 K to 10240 Kbps
 H.265: 14 K to 9984 Kbps
Day/NightAuto (ICR) / Color / B/W
BLC ModeBLC / HLC / DWDR
White BalanceAuto / Natural / Street Lamp / Outdoor / Manual
Gain ControlAuto / Manual
Noise Reduction3D DNR
Motion DetectionOff / On (4 Zone, Rectangle)
Region of InterestOff / On (4 Zone)
Smart IRSupported
Digital Zoom16x
Flip0° / 90° / 180° / 270°
MirrorOff / On
Privacy MaskingOff / On (4 Area, Rectangle)
Audio
CompressionG.711a / G.711Mu / AAC / G.726
InterfaceBuilt-in Microphone
Network
EthernetRJ-45 (10/100 Base-T)
ProtocolHTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP;
 FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS;
 UPnP; NTP; Bonjour; 802.1x; Multicast; ICMP;
 IGMP; SNMP
InteroperabilityONVIF, PSIA, CGI
Streaming MethodUnicast / Multicast
Max. User Access10 Users /20 Users
Edge StorageNAS
 Local PC for Instant Recording
 MicroSD Card, maximum 128 GB
Web ViewerIE, Safari
Management SoftwareSmart PSS, DSS
Mobile Operating SystemIOS, Android
Certifications
SafetyUL60950-1
Electromagnetic CompatibilityFCC Part 15 Subpart B
Electrical
Power SupplyDC12V, PoE (802.3af, Class 0)
Power Consumption< 5 W
Environmental
Operating Conditions-30° C to +60° C (-22° F to +140° F),
 Less than 95% RH
Storage Conditions-30° C to +60° C (-22° F to +140° F),
 Less than 95% RH
Ingress Protection IP67
Construction
CasingMetal
DimensionsΦ106.0 mm x 93.70 mm (Φ4.17 in. x 3.69 in.)
Net Weight0.47 kg (1.04 lb)
Gross Weight0.65 kg (1.43 lb)
