NVR301-04L-P4 - UNV Uniview - 4CH 4K IP 1 SATA NVR
The UNV (Uniview) 4K Recording Resolution 1 SATA Network Video Recorder
This 4K recording resolution 1 SATA network video recorder is equipped with top of the line technology that is aimed at keeping you well protected around the clock and updated wherever you go. Supporting a cutting edge central monitoring system software that allows you to link an unlimited number of cameras or recorders to a single IP address while supporting up to 4 different IP channel inputs.
Boasting of a recording resolution of up to 8MP which translates to phenomenal 4K display resolution on your screens which make up for clear 1080p footage.
This powerful recording and display resolutions are made possible by its inbuilt H.264 compression that reduces your file size without disrupting any quality, and furthermore the H.265 compression ability that allows you to enjoy great resolution at amazingly low bandwidth sources. All this saves precious time and hard disk space.
Along with all of these features this unique video recorder has various other features such as remote control of your PTZ cameras, push alerts (automatic email upon any motion detection) and various other custom design suited for the best of your surveillance needs.
Product Features
- 4 IP Channel Inputs
- 4 Independent 100Mbps 802.3at PoE+ Interfaces
- 1 HDMI and 1 VGA Video Outputs
- Up to 8MP (4K) Recording Capability
- Support Ultra 265/H.265/H.264 video formats
- 1 10/100Mbps Network Interface
- 1 SATA Interfaces for Internal Storage
- ONVIF Complianth
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
Uniview: The Rising Star of the CCTV World
This Uniview NVR has the capability to record on 4 IP surveillance cameras channels. With its super strong SATA hard drive you can procure 8 TB of storage. You can either save your footage for later watching or view it while it is being taped.
The NVR maintains third party IP security cameras as well. Connect to your NVR from multiple IP address and locations with no hassle. Numerous recording and playback options and even one for scheduled recording.
The Ultra 265 compressing feature helps in keeping the quality of your footage in tip top shape but decreasing the size of the file so as you can use and keep numerous files.
World Eye Cam has a free consultation and system design system that you can make good use of by calling us on (1-888-211-2288) or shoot us an email.
Our services are open from Monday to Friday 8 AM – 5 PM Pacific Time (PT).
The UNV (Uniview) 4-ch 1-SATA PoE NVR. This Uniview NVR records 4 channels of IP surveillance cameras. It supports third-party IP cameras with ONVIF compliance. The NVR can record up to a 8MP resolution and has a SATA HDD for up to 8TB of storage. Footage can be viewed in real time or saved for later viewing.
Features
- 4-channel input
- Third-party IP cameras supported with ONVIF conformance
- HDMI to 4K Resolution VGA up to 1080P
- Up to 8 Megapixels resolution recording
- Accurate retrieval, instant playback
- 1 SATA HDD up to 8 TB
- Plug & Play with 4 independent PoE network interfaces
- Support for P2P, UPnP, NTP, DHCP, PPPoE
- Support for mobile client access
NVR Features
Remote Monitoring
Central Monitoring System: Have more than one location? Well accessing each of them on a different IP address is a thing of the past with our standard CMS software that allows you to painlessly link an almost unlimited number of recorders and cameras all to the same IP address.
Playback and Recording
Multiple Playback and Recording Options: The multiple recording options allow you to set your Universal DVR/NVR to record on a set schedule, continuously around-the-clock, or to further conserve hard drive space: only when motion is detected. You can also select the number of cameras to view on one screen or hide certain ones from other users, using the multiple playback features.
Ultra 265 Compression
Ultra 265 Real-time Recording and Playback: Its Ultra 265 compression greatly reduces the size of your digital video files without compromising the image quality (compared to other compression standards, such as H.264 and MJPEG). Ultra 265 is a stable, proven compression technology, which offers unbeatable recording picture quality while at the same time saving you valuable hard drive storage space.
Push Alerts
Push Alerts & Automatic E-mails: Setup your Universal DVR/NVR to automatically send you an e-mail alert or a Push Notification, with video clip, every time there is a motion triggered event. This enables you to quickly take action when an incident has occurred.
E-map Function
E-map Function Support: The E-map feature provides a camera icon that represents the location of cameras on a map of a building or area, helping you to strategically place your cameras in the spots where surveillance is most needed. The detail this function provides is essential in saving time and the hassle of re positioning your cameras to achieve the desired viewing space.
PTZ Control
3D Intelligent Positioning: This features let you digitally control your PTZ cameras (move up, move down, move left, move right, zoom in and zoom out) from your monitor and mobile applications.
Custom System Design
Worldeyecam offers free consultations and system designs, so if the bundled kits don't have what you need, please do not hesitate to call us (1-888-211-2288) or send in a sales request or e-mail. We are open Monday through Friday at 8AM to 5PM Pacific time.
**There are NO contracts or monthly fees with any WorldEyeCam purchase**
| SPECIFICATIONS | |
| Model | NVR301-04L-4P |
| Video/Audio Input | |
| IP Video Input | 4-ch |
| Two-way Audio input | 1-ch, RCA |
| Network | |
| Incoming Bandwidth | 40Mbps |
| Outgoing Bandwidth | 96Mbps |
| Remote connection | 128 |
| Video/Audio Output | |
| HDMI/VGA output | HDMI1/VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz HDMI2: 4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Audio Output | 1-ch, RCA |
| Recording Resolution | 8MP/4MP/3MP/1080p/960p /720p/D1/2CIF/CIF |
| Synchronous Playback | 4-ch |
| Decoding | |
| Compression | Ultra 265, H.265, H.264 |
| Live view/ Playback | 8MP/4MP/3MP/1080p/960p /720p/D1/2CIF/CIF |
| Capability | 1 x 8MP@30FPS, 3 x 4MP@20, 4 x 1080p@30 |
| Hard Disk | |
| SATA | 1 SATA interfaces |
| Capacity | up to 8TB for each HDD |
| External Interface | |
| Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
| Network Function | HTTP, TCP/IP, IPV4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS,IP Filter, PPPOE, DDNS, FTP, IP Server, P2P |
| Serial Interface: | 1 x RS-485 |
| USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 |
| Alarm In | 8-ch |
| Alarm Out | 2-ch |
| PoE | |
| Interface | 4 independent 100 Mbps PoE network interfaces |
| Supported Standard | IEEE 802.3at |
| General | |
| Power Supply | 48V DC |
| Consumption ( without HDD and PoE ) | ≤ 8 W |
| PoE | Max 30W for single port Max 200W in total ( 12.5W for each ) |
| Working Temperature | -10℃~ + 55℃ ( +14℉ ~ +131℉) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 44 * 360 * 254mm (1.7" * 14.2" * 10.0" ) |
| Weight ( without HDD ) | ≤ 1.42 Kg ( 3.13 lb ) |
- ManufacturerUniview
- Number of Channels4ch
- Recorder TypeNVR (with POE Ports)
- Hard DriveI will install my own hard drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive
- Warranty3 Year warranty
- Remote Login SupportNo Login Support Needed, 1 Time FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
