        NVR316-64R-B - UNV Uniview - 64CH NVR - ULTRA PRO 16HDD Series

        Uniview
        SKU: NVR316-64R-B

        The UNV (Uniview) 64-ch 8-SATA RAID NVR.

        Features

        • 64-channel input
        • Third-party IP cameras supported with ONVIF conformance
        • Support 2-ch HDMI, 1-ch VGA, 1-ch CVBS, HDMI2 at up to 4K(3840x2160) resolution
        • Up to 12 Megapixels resolution recording
        • Support H.265/H.264 video formats
        • Accurate retrieval, instant playback
        • Support HDD hot swap with RAID1, 5 storage scheme configurable
        • 8 SATA HDDs, Up to 8TB for each HDD
        • Support various VCA detection alarm and VCA search
        • Support N+1 Hot space
        • Support for 12V Power output
        • Support for P2P, UPnP, NTP, DHCP, PPPoE
        • Support for mobile client access
          • 47% less
          Market price:$8999.00 save $4270.00
        • $4729.00

        OR

        The UNV (Uniview) ULTRA PRO 64-ch 16-SATA RAID NVR.

        PRODUCT FEATURES

        • 64-channel input
        • Third-party IP cameras supported with ONVIF conformance
        • Support 2-ch HDMI, 1-ch VGA, 1-ch CVBS, HDMI2 at up to 4K(3840x2160) resolution
        • Up to 12 Megapixels resolution recording
        • Support Ultra 265/H.265/H.264 video formats
        • Accurate retrieval, instant playback
        • Support RAID 0, 1, 5, 6, 10, 50, 60 Storage Schemes
        • 16 SATA HDDs, Up to 8TB for each HDD
        • Support various VCA detection alarm and VCA search
        • Support N+1 Hot space
        • Support for 12V Power output
        • Support for P2P, UPnP, NTP, DHCP, PPPoE
        • Support for mobile client access
        • Support cloud upgrade
        • Various fisheye dewarping modes for live view and playback for both web interface and GUI
        • ANR Technology to enchance the storage reliability when the network is disconnected





        NVR Features

        Remote Monitoring

        Central Monitoring System: Have more than one location? Well accessing each of them on a different IP address is a thing of the past with our standard CMS software that allows you to painlessly link an almost unlimited number of recorders and cameras all to the same IP address.

        Playback and Recording

        Multiple Playback and Recording Options: The multiple recording options allow you to set your Universal DVR/NVR to record on a set schedule, continuously around-the-clock, or to further conserve hard drive space: only when motion is detected. You can also select the number of cameras to view on one screen or hide certain ones from other users, using the multiple playback features.

        H.264 Compression

        H.264 Real-time Recording and Playback: Its H.264 compression greatly reduces the size of your digital video files without compromising the image quality (compared to other compression standards, such as M-JPEG and MPEG-4). H.264 is a stable, proven compression technology, which offers unbeatable recording picture quality while at the same time saving you valuable hard drive storage space.

        H.265 Compression

        H.265 Real-time Recording and Playback: H.265 is a step above H.264. In the world of technology, we all strive to move forward and advance--so here is our next offer in the world of saving space and slow internet speeds. H.265 can transfer HD video data (~720p) at half of the bandwidth then that of H.264 so that you can enjoy 2K and 4K videos even if you have slow internet(1~2Mbs). You get the same data quality as H.264 and the others, but compared you save 70~80% in bandwidth sources.

        Push Alerts

        Push Alerts & Automatic E-mails: Setup your Universal DVR/NVR to automatically send you an e-mail alert or a Push Notification, with video clip, every time there is a motion triggered event. This enables you to quickly take action when an incident has occurred.

        E-map Function

        E-map Function Support: The E-map feature provides a camera icon that represents the location of cameras on a map of a building or area, helping you to strategically place your cameras in the spots where surveillance is most needed. The detail this function provides is essential in saving time and the hassle of re positioning your cameras to achieve the desired viewing space.

        PTZ Control

        3D Intelligent Positioning: This features let you digitally control your PTZ cameras (move up, move down, move left, move right, zoom in and zoom out) from your monitor and mobile applications.

        Custom System Design

        Worldeyecam offers free consultations and system designs, so if the bundled kits don't have what you need, please do not hesitate to call us (1-888-211-2288) or send in a sales request or e-mail. We are open Monday through Friday at 8AM to 5PM Pacific time.



        **There are NO contracts or monthly fees with any WorldEyeCam purchase**



        SPECIFICATIONS
        ModelNVR316-64R-B
        Video/Audio Input
        IP Video Input64-ch
        Two-way Audio input1-ch, RCA
        Network
        Incoming Bandwidth320Mbps
        Outgoing Bandwidth320Mbps
        Remote connection128
        Video/Audio Output
        HDMI/VGA outputHDMI1/VGA:
        1920x1080p /60Hz,
        1920x1080p /50Hz, 1600x1200 /60Hz,
        1280x1024 /60Hz, 1280x720 /60Hz,
        1024x768 /60Hz
        HDMI2:
        4K (3840x2160) /60Hz,
        4K (3840x2160) /30Hz,
        1920x1080p /60Hz,
        1920x1080p /50Hz, 1600x1200 /60Hz,
        1280x1024 /60Hz, 1280x720 /60Hz,
        1024x768 /60Hz
        Corridor Mode Split3/4/5/7/9/10/12/16
        CVBS Output1-ch, BNC
        Audio Output1-ch, RCA
        Recording Resolution12MP/8MP/6MP
        /5MP/4MP/3MP/1080p
        /960p/720p/D1
        /2CIF/CIF
        Synchronous Playback16-ch
        Decoding
        CompressionUltra 265/H.265/H.264
        Live view/ Playback12MP/8MP/6MP
        /5MP/4MP/3MP/1080p
        /960p/720p/D1/
        2CIF/CIF
        Capability3 x 12MP@25,
        4 x 4K@30, 8 x 4MP@30, 16 x 1080p@30,
        36 x 720p@30,
        64 x D1
        Hard Disk
        SATA16 SATA interfaces
        Capacityup to 8TB for each HDD
        Disk array
        Array TypeRAID0.RAID1,RAID5,RAID6,RAID10,RAID50,RAID60
        External Interface
        Network Interface2 RJ-45 10M/100M/1000M
        self-adaptive Ethernet Interface
        Network FunctionHTTP, TCP/IP, IPV4,
        UPNP, RTSP, UDP, SMTP, NTP, DHCP,
        DNS,IP Filter, PPPOE, DDNS,
        FTP, IP Server, P2P
        Serial Interface:1 x RS-232, 1 x RS-485
        USB InterfaceRear panel: 2 x USB2.0, 1 x USB3.0
        Alarm In16-ch
        Alarm Out4-ch
        General
        Power Supply 1100 ~ 240V
        Consumption
        ( without HDD )        		±20 W
        Working Temperature-10℃~ + 55℃
        ( +14℉ ~ +131℉)
        Working Humidity10% ~ 90%
        Dimensions86 * 442 * 531mm
        (3.4" * 17.4" * 19.9" )
        Weight ( without HDD )≤ 5.13Kb Kg
        ( 11.31 lb )


        Data sheet of NVR308R Series

        Full Screen-Network Video Recorders User Manual-V1.04

        UNV Network Video Recorders Quick Guide-V1.00



          • SKU
            NVR316-64R-B
          • Weight
            12 lbs
        • Manufacturer
          Uniview
        • Number of Channels
          64ch
        • Recorder Type
          NVR (with POE Ports)
        • Hard Drive #1
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #2
          I will install my own hard drive, 500GB HDD, 1TB HDD, 2TB HDD, 3TB HDD, 4TB HDD
        • Hard Drive #3
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #4
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #5
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #6
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #7
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #8
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #9
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #10
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #11
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #12
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #13
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #14
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #15
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Hard Drive #16
          I Will Install My Own Hard Drive, 1 TB Hard Drive, 2 TB Hard Drive, 3 TB Hard Drive, 4 TB Hard Drive, 6 TB Hard Drive, 8 TB Hard Drive
        • Warranty
          3 Year warranty
        • Remote Login Support
          No Login Support Needed, 1 Time FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
