UNV Uniview 8 Ch NVR & (8) 5 Megapixel Starlight IR Motorized Turret Dome Kit Professional Grade
Uniview: The Rising Star of the CCTV World
How to Program Your Uniview EZView App on Your Mobile Device
These are 4MP Network IR Fixed Dome Cameras. They have a motorized varifocal lens size from 2.7mm~12mm. This lens size will vary your Angle of View from 91°~27°. Infrared night vision allows the security camera to see up to 98 feet in total darkness. These surveillance cameras are ONVIF compliant. They come with a built in audio microphone to allow both audio and video surveillance.
Optics
- Day/night functionality
- Optical glass window with higher light transmittance
- Up to 120 dB WDR (Wide Dynamic Range)
- IR anti-reflection window to increase the infrared transmittance
- 3D Noise Reduction
The UNV (Uniview) 4K UltraHD Recording Resolution Network Video Recorder
The UNV (Uniview) 4K UltraHD Recording Resolution Network Video Recorder brings to you many features like remote monitoring where you can easily hook up various security cameras to your IP address. Other features include numerous multiple recording and playback options. With these options you can schedule recordings on a given time or all around the clock.
The H.264 compressing feature helps in keeping the quality of your footage in tip top shape but decreasing the size of the file so as you can use and keep numerous files. The NVR also comes with a H.265 which enables you to watch 2K and 4K videos even if you have slow internet like 1 to 2 Mbs. Enable the push alert notifications and automatically receive an email whenever a sudden movement is captured on tape. This helps you in quickly getting in to action whenever an incident happens. Also you can control the positioning of your camera with the controls on this NVR.
The UNV (Uniview) 4K UltraHD Recording Resolution Network Video Recorderbrings to you many features that include; 16 IP Chanel inputs as well as recording of 12 megapixels resolution and 16 100M PoE+ Ports. Other features include numerous multiple recording and playback options and 12 TB worth of HDD storage space. With these options you can schedule recordings on a given time or all around the clock.This NVR is ONVIF compliant!
The H.264 compressing feature helps in keeping the quality of your footage in tip top shape but decreasing the size of the file so as you can use and keep numerous files. The NVR also comes with a H.265 which enables you to watch 2K and 4K videos even if you have slow internet like 1 to 2 Mbs. Enable the push alert notifications and automatically receive an email whenever a sudden movement is captured on tape. This helps you in quickly getting in to action whenever an incident happens. Also you can control the positioning of your camera with the controls on this NVR.
Product Features
- 16 IP Channel Inputs
- 16 Independent 100M PoE+ Ports
- 1 HDMI and 1 VGA Video Outputs
- Up to 12 Megapixels resolution recording
- Support H.265/H.264 video formats
- 1 RJ-45 10/100/1000M Ethernet Interface
- 2 SATA Interfaces for Internal Storage
- ONVIF Compliant
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
The UNV Uniview 8 Ch NVR & (8) 5 Megapixel Starlight IR Motorized Turret Dome Kit is a professional-grade surveillance system that includes an 8-channel network video recorder (NVR) and 8 motorized turret dome cameras. This kit is designed to provide high-quality video surveillance for businesses, homes, or any other property.
The NVR included in the kit is capable of recording and managing up to 8 IP cameras, making it a great choice for small to medium-sized surveillance systems. It supports H.265 video compression, which allows for efficient storage and transmission of high-quality video footage. The NVR also features a user-friendly interface and can be accessed remotely through a web browser or mobile app.
The 8 motorized turret dome cameras included in the kit are 5-megapixel cameras that feature Starlight technology, which provides clear, high-quality images even in low-light conditions. The cameras also have IR (infrared) illumination that enables them to capture images in complete darkness. The motorized turret design allows for easy adjustment of the camera's viewing angle, and the dome design makes the cameras vandal-resistant.
Overall, the UNV Uniview 8 Ch NVR & (8) 5 Megapixel Starlight IR Motorized Turret Dome Kit is an excellent choice for those looking for a professional-grade surveillance system that is easy to set up and use. It offers high-quality video footage, remote access, and a range of features that make it an ideal choice for businesses or homes. If you're looking for a reliable and efficient surveillance system, this kit is definitely worth considering.
How to Program Your Uniview EZView App on Your Mobile Device
The most cost effective professional grade solutions from Uniview. The 8ch NVR and 4MP motorized turret dome camera kit can support high resolution live view and playback up to 4K(4000x3000). This NVR supports 1-8TB surveillance hard drives for increased storage and efficiency. All cameras are equipped with the latest Ultra 265 Video codec for reduced storage needs without losing any video quality. The NVR is integrated with a 4 port PoE switch to provide the connected cameras both power and data up to 928ft. (with extended transmission enabled)
This kit includes eight 4MP motorized turret dome security cameras with 98ft of SmartIR night vision. It records high definition footage in 4MP (2K) resolution and is outdoor rated. All footage is recorded onto the included NVR and can be monitored remotely via mobile device or computer.
What’s Included:
· (1) 8 Ch, 8 Poe, 4K NVR
· (8) Uniview 4 Megapixel Motorized Turret Dome IP Camera
· 1TB Surveillance Hard Drive
· 8x 100ft Cat5e Cables
· Free mobile apps and monitoring software
· Free lifetime technical support
· Free 3 Year Warranty
·HDMI & VGA Ports: Take full advantage of high definition video by using either HDMI or VGA cables.
·Remote Monitoring through our Free Apps: Download our free apps and view live footage and recordings right on your compatible smartphone or tablet.
·PC and Mac Compatible: Take advantage of the flexibility that our systems offer and review your recordings from any Mac or PC.
·Easy Backup Options: Save footage directly to a USB flash drive or to your PC in seconds flat. Options are also available to backup footage simultaneously to external SATA drives or FTP servers on your network, in the case that your main HDD should fail.
Highlighted Features
U.265 Compression
By combining U-Code and H.265, Ultra 265 can squeeze up to 95% bandwidth and storage space.
Unlike conventional video compression technologies which tries to reduce storage costs by sacrificing resolution and frame rate indiscriminately, U-Code chooses to use "IRP" (Intelligent Region Perception) to detect motion in each frame. Hence, scenes containing interesting information could be preserved while the other relatively static area such as lawns, white walls could be squeezed to save storage.
Cloud Upgrade
If your NVR is connected to a network with Internet access, you may utilize the Internet cloud update feature to check online to see if a new version is available and to perform the update.
Bring up the main menu by right-clicking with the mouse or left-clicking on the Home icon on the menu bar (if available). Using the mouse, left-click on Maintain and then Upgrade and then select the tab entitled Upgrade by Cloud. You will be shown the current version of firmware installed on the NVR and can click on the Check button at the bottom to see if a more recent version is available. If a new version is available, you need only to click on the Upgrade button at the bottom and the download and upgrade process will begin. After updating, the NVR will automatically reboot.
Smart Playback
In normal search, you had to take hours to search the whole playback bar to find the desired video clip.
In smart search, specify an interesting area and do smart search, it only takes seconds to find the desired video clip
Mobile App Push Notifications
Push Alerts & Automatic E-mails: Setup your Universal DVR/NVR to automatically send you an e-mail alert or a Push Notification, with video clip, every time there is a motion triggered or alarm event. This enables you to quickly take action when an incident has occurred
E-Map Function
The E-map feature provides a camera icon that represents the location of cameras on a map of a building or area, helping you to strategically place your cameras in the spots where surveillance is most needed. The detail this function provides is essential in saving time and the hassle of re positioning your cameras to achieve the desired viewing space.
**There are NO contracts or monthly fees with any WorldEyeCam purchase**
| Model | NVR301-08-P8 |
|---|---|
| Video/Audio Input | |
| IP Video Input | 8-ch |
| Network | |
| Incoming Bandwidth | 60Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
| Video/Audio Output | |
| HDMI/VGA Output | HDMI: 3840x2160p /30hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Synchronous Playback | 8-ch |
| Corridor Mode Screen | 3/4/5/7/9 |
| Decoding | |
| Decoding format | Ultra 265/H.265/H.264 |
| Live view/ Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 1 x 4K@30fps, 2x 4MP@30FPS, 4 x 1080P@30, 4 x 720P@30 |
| Hard Disk | |
| SATA | 1 SATA interface |
| Capacity | Up to 8TB for each HDD |
| External Interface | |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0 |
| PoE | |
| Network Interfaces | 8 independent 100 Mbps PoE |
| Max Power | Max 30W for single port. Max 108W in total ( 13.5W for each ) |
| Supported Standards | IEEE 802.3at, IEEE 802.3af |
| General | |
| Power Supply | 52V DC Power Consumption: ≤ 5 W( without HDD ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
| Dimensions(W×D×H) | 260mm ×240mm × 44mm (10.2" × 9.4"× 1.7") |
| Weight ( without HDD ) | ≤ 1.12Kg(2.47lb) |
| Model | IPC3635ER3-DUPZ |
| Camera | |
| Sensor | 1/2.7", progressive scan , 5.0 megapixel, CMOS |
| Lens | 2.7~13.5 mm,AF automatic focusing and motorized zoom lens |
| DORI Distance | Lens: 2.7mm: Detect (60.8m), Observe (24.3m), Recognize (12.2m), Identify (6.1m) 13.5mm: Detect (303.8m), Observe (121.5m), Recognize (60.8m), Identify (30.4m) |
| Angle of View (H) | 93.38°~28.56° |
| Angle of View (V) | 88°~16.4° |
| Angle of View (O) | 121.4°~33.7° |
| Adjustment angle | Pan: 0°~360°; Tilt: 0°~90°; Rotate: 0°~360° |
| Shutter | Auto/Manual, 1/1~1/100000 s |
| Min. Illumination | Colour: 0.002 Lux (F1.2, AGC ON) 0 Lux with IR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Digital noise reduction | 2D/3D DNR |
| S/N | >52dB |
| IR Range | Up to 30m (98 ft) IR range |
| Defog | Digital Defog |
| WDR | 120dB |
| AWB (Auto White Balance) | Auto/Manual |
| Gain Control | Auto/Manual |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream: 5MP (2592×1944): Max. 20 fps; 4MP (2560×1440): Max. 30 fps; 3MP (2048×1520): Max. 30 fps Sub Stream: 2MP (1920×1080): Max. 30 fps; Third Stream:D1 (720×576): Max. 30 fps |
| 9:16 Corridor Mode | Supported |
| HLC | Supported |
| BLC | Supported |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 8 areas |
| ROI | Up to 8 areas |
| Motion Detection | Up to 4 areas |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication, |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network Storage | ANR |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, |
| Compatible Integration | ONVIF(Profile S, Profile G), API |
| Interface | |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Audio | Built-in Mic |
| Audio Compression | G.711 |
| General | |
| Power | 12 V DC(+/-25%); PoE (IEEE802.3 af) Power consumption: Max 8.16W |
| Dimensions (Ø x H) | Φ129 x 110 mm (Ø5.08” x 4.3”) |
| Weight | 0.82 kg (1.8 lb) |
| Working Environment | -40°C ~ +60°C (-40°F ~ 140°F), Humidity:10%~90% RH(non-condensing) |
| Ingress Protection | IP67 |
| Reset Button | Supported |
- ManufacturerUniview
- Hard Drive # 1FREE 1TB HDD, 2TB HDD, 4TB HDD, 6TB HDD, 8TB HDD
- Upgrade NVRNone, 16ch NVR Upgrade
- CAT5 CABLEFree 8 X 100 Ft RJ45, 1000 FT Cat5e
- MonitorI will use my own monitor, 22 inch LCD Flat Panel 249.00 $, 24 inch LCD Flat Panel 299.00 $
- NVR and Cameras Warranty3 Year Warranty
- Remote loginNo Login Support Needed, FREE Setup: Remote Access Mobile App Configuration - Motion Detection Setup
