UVR104-N 4 Channel 1080N Universal Analog CVBS, AHD, TVI, CVI and IP DVR, 1 SATA HDD
SKU: UVR104-NThis Universal Recorder records audio and video from up to four 1080P Analog CVBS, AHD, TVI, CVI and IP surveillance cameras. It can record up to 1080N resolution on all cameras at up to 12fps and supports 4 channels of audio input.
- Shipping info
We deliver worldwide
- Payment methods
- Return Policy
We accept returns
- Customer Reviews
Check out our customer Reviews
This Universal Recorder records audio and video from up to four 1080P Analog CVBS, AHD, TVI, CVI and IP surveillance cameras. It can record up to 1080N resolution on all cameras at up to 12fps and supports 4 channels of audio input.
Features
- 4 Channel HD Analog up to 1080n Resolution
- Supports Analog CVBS, AHD, TVI, CVI and IP
- Mixed input mode allows for ONVIF compliant IP camera connections up to 720p resolution.
- 4 Channels of audio input
- VGA and HDMI video output ports
SPECIFICATIONS | |
Model | WEC104-N |
Video Inputs | 4 channel, BNC |
Video Codec | H.264 |
Audio Inputs | 4 Channels |
Audio Outputs | 1 Channel |
Two Way Talk | Supported |
Audio Compression | G.711a |
Display Interface | 1 VGA, 1 HDMI |
Display Resolution | Up to 1080p |
Display Split | 1 / 4 |
Privacy Masking | Up to 4 independantly configurable regions |
Recording Resolution | Up to 1080n (960 x 1080) @ 12fps Analog |
Camera Input Mode | All analog, 2 analog + 2IP (maximum resolution of 720p), all IP |
Recording Mode | Manual, Schedule (Continuous, Motion Detect, Alarm), Stop |
Playback Channels | Up to 4 Simultaneous channels |
Trigger Event | Record, Tour, Message display, E-mail, Buzzer, PTZ call, FTP |
Motion Detection | 192 (16 x 12) sensor regions |
Alarm Inputs | N/A |
Relay Outputs | N/A |
Backup Media | USB Media or network download |
Network Interface | 1 RJ-45 10/100M Ethernet Port |
HDD Interfaces | 1 SATA Port (up to 6TB) |
USB Interfaces | 2 USB2.0 Ports |
RS-485 Interfaces | 1 Terminal block connection for PTZ control (multiple protocols supported) |
General | |
Power Requirement | DC12V 2A |
Dimensions | 10.1” x 9.3” x 1.8” (255mm x 236mm x 44mm) |
Weight | 2.3 lbs |
Shipping Weight | 7 lbs |
